- Type:SMD LED
- Chip Material:InGaN
- Emitting Color:Tri-Color(Red-Blue-Green)
- Place of Origin:CN;GUA
- Certification:CE
- Certification:RoHS
- Power:0.2w
- Luminous Intensity:R:620-630nm G:520-530nm B:460-470nm
- Luminous Flux(lm):R:1.8-2.4 G:4.2-4.8 B:0.9-1.5
- Optical Attenuation(%):2
- Power Dissipation:5
- Viewing Angle(°):120
- Color Rendering Index(Ra):85
- Color Temperature:620-630nm 520-530nm 460-470nm
- Operating Temperature(℃):0 - 80
- Storage Temperature(℃):5 - 30
- Brand Name:YLL
 | Product Information | |
| Model number | YLL-5060RGB | |
| Luminous | R:500-700mcd,G:1400-1600mcd,B:300-500mcd | |
| View Angle | 120 degree | |
| Voltage | Red: 2.0-2.4V Green: 3.0-3.4V Blue:3.0-3.4V | |
| Current | 20mA | |
| Lifespan | 50000 hours | |
| Warranty | 2 Years | |
-Thermo electric Separation
-Dead lamp-Proofing
-Sulfide-proofing
-moisture-proofing
-High brightness
-wide beam angle
-Low impendence
-Good heat disspitation
We are committed to the development of durable, cost-effective products
1.Epistar proof document,Pass Energy Star LM80 and CE ROHS
2.Long Lifespan 100000hours
3.Low Light Decay
4.Enviornmental protection,No Mercury.
5.Energy Saving
6.Fast Response Time,response in dozens of ns,safely.
7.Small Volume, Light Weight,Shock-proofing
8.High Lumens,Light Source Stable ,Low Heat Dissipation
9.Easy to adjust the light and color temperature
-Flexible and Hard Strip light
-Guardrail Tube
-Point Light Source
-Module
-Outdoor Lamps
Shenzhen Yuliang Optoelectronic Techology Co.,Ltd has successfully passed ISO9001:2008, and all products are available for CE-EMC,CE-LVD, ROHS,LM-80 Certification Testing.
We strictly control product quality
Raw Material inspection and quality status analysis to ensure raw materials Mission's requirements.
According raw material supplier quality record. Raw material supplier will be sifted out by our company if their yield rate under 93%.
Two-year Warranty
Return or replacement within two years if there have any defected product or malfunctioning product or broken product.
Exchange & Return Policy
1)The shipment cost should be taken by supplier if there have defected product or malfunctioning product or broken product within two years.Replacement will be sent to you in your next order if you don’t want to return.
2)0.3% free spare part for volume order,in the same time,we will give you replacement as compensation with next order if faulty product rate reach to 0.3%.
YLL Lighting is committed to creating high-quality, affordable, well-designed and energy efficient LED lighting that make it easy for customers to sell, electricians to install and endusers to save energy.
YLL Lighting established in 2001,we located in Silicon Valley Power Industrial Park Guanlan Town,Shenzhen,China,YLL has a building which Covering an area of 6000 sq.m,certified by TUV according to ISO9001,YLL Lighting have its own packaging production line,more than 30 automatic production lines for LED well-designed, professional grade lighting,our light source listed by energy star
lm-80 certificate.
