- Type:SMD LED
- Place of Origin:CN;GUA
- Color Temperature:B:460-470nm
- Brand Name:YLL
- Model Number:YLL3528
- Power Dissipation:0
- Power:0.06W
- Luminous Flux(lm):600-800mcd
- Luminous Intensity:600-800mcd
- Storage Temperature(℃):0 - 40
- Optical Attenuation(%):0.5
- Viewing Angle(°):50-60
- Chip Material:AlGaInP
- Certification:CE
- Certification:RoHS
- Emitting Color:Blue
- Operating Temperature(℃):-20 - 40
Blue color Epistar chip 3528 lens smd led chip for brake light
Product data | |
Emitting Color | Blue |
Wavelength | 460-470nm |
Luminous flux | 600-800mcd |
View Angle | 50-60degree |
Voltage | 3.0-3.4V |
Current | 20mA |
Lifespan | 50000 hours |
Warranty | 2 Years |
Size | 3.5*2.8*2mm |
Feature |
|
-Moisture-Proofing -Dead Lamp-Proofing -Sulfide-Proofing -Good Heat Dissipation -Low Light Decay | |
Application | |
-Flexible and Hard Strip Light -Guardrail Tube -Point Light Source -Module -LED Display | |
Absolute Maximum Ratings at TA=25℃
Electrical / Optical Characteristics at TA=25℃
Optical Characteristics
Product application
Yuliang LED 3528 Convex Head SMD is widely applying for
Outdoor Point Light Source, Fence Tube,Wall Washer Light,Line Lamp,Intelligence home lighting etc
